*1 The range varies depending on factors such as the connected DC power supplies and electronic loads, the wiring configuration of the system, and the charge/discharge operation. *2 The minimum voltage that can be discharged varies depending on factors such as the connected electronic load models and the wiring configuration.

Static

Constant current charge/discharge

Constant voltage charge/discharge

Constant cell voltage charge/ discharge *4

Constant power discharge

Pattern *6

Pattern constant current

Pattern constant power

*1 The range varies depending on factors such as the connected DC power supplies and electronic loads and the wiring configuration of the system. *2 Ambient temperature at 18 °C to 28 °C *3 The external devices are controlled through software so that the measured values are equal to the settings. The accuracy of the settings is the same as the measurement accuracy. Because this is dependent on the control cycle, correct control may not be possible for a DUT (battery) with high impedance or a DUT whose circuit is open. Control cycle for constant current / constant voltage control is 1 ms and for constant cell voltage control is 100 ms. *4 Can be set only when the optional Volt / Thermometer Unit OP02-PFX or OP03-PFX Voltmeter Unit is installed. *5 The battery voltage is measured, and the control current (constant current control) is calculated from the set power value through software calculation. The time required to process one calculation (from the voltage measurement to the output setting) is approximately 1 ms. *6 The operating voltage range is 1 V or more (when the TL10-PFX is being used; regardless of whether a bias DC power supply is being used). *7 With battery voltage of 2 V or more.

Static

Charge / discharge current measurement

Voltage measurement

Power measurement

Current capacity calculation

Power capacity calculation

Time *6

Pattern

Charge / discharge current measurement

Voltage measurement

Power measurement

Current capacity calculation

Power capacity calculation

Time *6

*1 Measurable range: -210.000 A to 210.000 A (TYP). However, the accuracy is not guaranteed for values outside of the range listed in the table. *2 Ambient temperature at 18 °C to 28 °C. *3 Measurable range: -6.500 V to 65.000 V (TYP). However, the accuracy is not guaranteed for values outside of the range listed in the table. *4 Measurable range: -6.500 V to 6.500 V (TYP). However, the accuracy is not guaranteed for values outside of the range listed in the table. *5 The same for the 6 V range and 60 V range. *6 Accuracy of the elapsed time (Cutoff condition) when charging / discharging or resting. *7 Monthly error: approximately 30 seconds.

High speed sampling

Current measurement

Voltage measurement

*1 The accuracy is not guaranteed for values outside of the rated output range. *2 Ambient temperature at 18 °C to 28 °C. *3 The wavering caused by the ripple noise and AC line noise (50 Hz/ 60 Hz) of the DC power supply that you are using is not included. *4 Measurable range: -6.500 V to 65.000 V (TYP). However, the accuracy is not guaranteed for values outside of the range listed in the table. *5 Measurable range: -6.500 V to 6.500 V (TYP). However, the accuracy is not guaranteed for values outside of the range listed in the table. *6 The same for the 6 V range and 60 V range.

*The thermistor 103AT-2 (SEMITEC Corporation) is used for temperature detecting element.

Resistor (temperature) measuring section *1

Reference (thermistor 103AT)

*1 The temperature measurement does not trace the absolute temperature. Temperature converted from resistance. *2 Excludes temperature detector errors. *3 Ambient temperature at 18 °C to 28 °C

*1 For the software OCP, the application software automatically sets a value obtained by adding 5 A to the preset current. *2 The application software calculates the value by multiplying the nominal capacity by the preset percentage and sets the capacity.

*1 DoesnotapplytospeciallyorderedormodifiedPFX2512sandPFX2532s. *2 Limited to products that have the CE/UKCA mark on their panels. When the optional OP03-PFX Voltmeter Unit is used, compliance is achieve by using the optional TL12-PFX sensing cable (length: approx. 3 m, connector area: with cover, with core). *3 ThisisaClassIequipment.BesuretogroundthePFX2512’sandPFX2532’sprotectiveconduc- tor terminal. The safety of this product is only guaranteed when the product is properly grounded. *4 Pollution is addition of foreign matter (solid, liquid or gaseous) that may produce a reduction of dielectric strength or surface resistivity. Pollution Degree 2 assumes that only non-conductive pol- lution will occur except for an occasional temporary conductivity caused by condensation. *5 This is a Class A equipment. The PFX2512 and PFX2532 is intended for use in an industrial environment. This product may cause interference if used in residential areas. Such use must be avoided unless the user takes special measures to reduce electromagnetic emissions to prevent interference to the reception of radio and television broadcasts. *6 This is a Group 1 equipment. The PFX2512 and PFX2532 does not generate and/or use intention- ally radio-frequency energy, in the from of electromagnetic radiation, inductive and/or capacitive coupling, for the treatment of material or inspection/analysis purpose. *7 Because the power cord does not comply with CE/UKCA, it may not be included depending on the shipment destination.
