Approx. 2.0mCompatible with PAD-L/LP series (*), PAK-A series, and PAN-A series*Excluding PAD600-1.5L and PAD1k-0.2L

For OP01-PIA and PMC-A (26-pin connector)Approx. 1.0m*Discontinued and only available while supplies last

For OP02-PIA and PMC-AApprox. 1.0m*Discontinued and only available while supplies last

Approx. 1.0m

Cable for series operation (for connection of 2 units in parallel) J1-J2 cable (40 cm): 1 (pre-assembled for series connection) Core: 1 / Binding: 2 Connector covers: 2 sets (top and bottom) Cover mounting screws: 4 (3 x 6), 2 (3 x 8)

Cable & Connector Set for External control J1 housing: 1 / J2 housing: 1 Wire (40 cm): 26 (pin crimped on one side) Core: 1 / Binding band: 1 Connector covers: 1 set (top and bottom) Cover mounting screws: 2 (3 x 6), 1 (3 x 8)

Parallel operation cable (for connecting two units in parallel) J1-J1 cable (40 cm): 1 (pre-assembled for parallel connection) Core: 2 Binding bands: 2 Connector covers: 2 sets (top and bottom) Cover mounting screws: 4 (3 x 6), 2 (3 x 8)

Parallel operation cable (for connecting 3 units in parallel) J1-J1-J1 cable (40 cm): 1 (pre-assembled for parallel connection) Core: 3 Binding bands: 3 Connector covers: 3 sets (top and bottom) Cover mounting screws: 5 (3 x 6), 3 (3 x 8)

AC cable (3-phase 200V)Length: 4mBoth ends unmachined

AC cable (3-phase 400V)Length: 4mBoth ends unmachined

Parallel operation cable (For 4 units in parallel)

Parallel operation cable (For 3 units in parallel)

AC cable (single-phase 200V)Length : 3mBoth ends unmachined

Parallel operation cable (For 2 units in parallel)

Serial link cable for RS485 connection L=0.5m

Three-phase: 4-coreLength: 4mNominal cross-sectional area:8m㎡Input terminal: M6

Flat cable 250mm

RS232C Connection Cable - Dsub9P Length: 2m

RS485 Connection Cable - Dsub9PLength: 2m

With U.S. plug13A,125V,2mNEMA5-15P type

disconnected 10A,250V,2m Non-plug type

With PSE for Japan 15A,125V,2m JIS C 8303 type

20 cables Housing for J1 connector / J2 connector x 1 each*Cable length 500mm (pin crimping processed)

With European plug.For Europe.10A, 250V, 2m.IEC60884-1 type

Signal cable for one-control parallel operation.

AC cable for 1500W model Total length 3mAC cable for PWX series optional 1500W model Total length 3m

Cable length: 2m

Power supply interlocking cable, 1m Multiple units of PCR-LE series can be powered on and off in tandem.

Single core: 3 pcs.Length : 3mNominal cross-sectional area:22m㎡Input terminal: M8

Cable length : 1m

Cable length : 2m

Cable length : 4m

3-core cabtyre cable Length : 3m Nominal cross-sectional area: 5.5 mm2 Input terminal:M4

Single core: 3 pcs.Length : 3mNominal cross-sectional area:8m㎡Input terminal : M5

Single core: 3 pcs.Length : 3mNominal cross-sectional area: 14m㎡Input terminal: M8

Single core: 3 pcs.Length : 3mNominal cross-sectional area: 14m㎡Input terminal: M6
