Connecting cable Extension cables for use when the attached connecting cable (0.7 m) or power signal cable is too short when changing the arrangement of the master machine or when connecting between different models. Extension connection cable: 1.3 m. Used for different model power differences o...

for slave unit operated in parallelTo use this product, the PCR-LE series main unit with firmware version 3.01 or later is required. If the firmware version of the product you own is 1.X or earlier, modifications, etc. are required, so please contact our sales department. Cannot be used with PC...

Parallel operation driver (for master unit)To use this product, the PCR-LE series main unit with firmware version 3.01 or later is required. If the firmware version of the product you own is 1.X or earlier, modifications, etc. are required, so please contact our sales department. Cannot be used...

Amplitude control type Amplifies the input waveform as it is and outputs it Controlled by external contact Monitoring of operating conditions

Amplitude control type Amplifies the input waveform as it is and outputs it Controlled by external contact Monitoring of operating conditions

LAN Interface This option is also available for the multi-output model (PCR-LE2).

GPIB Interface This option is also available for the multi-output model (PCR-LE2).

Maximum working voltage: 650V Maximum operating current: 500A Terminal: M12/M12 Nominal cross-sectional area: 150 mm2 (equivalent to AWG6/0) Total length / weight (per unit): approx. 3 m / 5 kg*Prices are for a set of two (for positive and negative poles). (DC150-4P3M-M12M12 is a set of 4 (2 f...

Maximum working voltage: 650V Maximum operating current: 300A Terminal: M12/M12 Nominal cross-sectional area: 150 mm2 (equivalent to AWG6/0) Total length / weight (per unit): approx. 3 m / 5 kg*Prices are for a set of two (for positive and negative poles). (DC150-4P3M-M12M12 is a set of 4 (2 ...

Maximum working voltage: 650V Maximum operating current: 200A Terminal: M12/M12 Nominal cross section: 80 mm2 (equivalent to AWG3/0) Total length / weight (per unit): Approx. 3 m / 2.8 kg*Prices are for a set of two (for positive and negative poles). (DC150-4P3M-M12M12 is a set of 4 (2 for po...

Maximum working voltage: 650V Maximum operating current: 200A Terminals: M12/M8 Nominal cross section: 80 mm2 (equivalent to AWG3/0) Total length / weight (per unit): Approx. 3 m / 2.8 kg*Prices are for a set of two (for positive and negative poles). (DC150-4P3M-M12M12 is a set of 4 (2 for pos...

Maximum working voltage: 650V Maximum Current: 100A Terminals: M12/M8 Nominal cross-sectional area: 38mm2 (equivalent to AWG1) Total length / Weight (per unit): Approx. 3 m / 1.4 kg*Prices are for a set of two (for positive and negative poles). (DC150-4P3M-M12M12 is a set of 4 (2 for pos...

Maximum working voltage: 650V Maximum Current: 50A Terminals: M12/M8 Nominal cross-sectional area: 14mm2 (equivalent to AWG5) Total length / Weight (per piece): Approx. 3m / Approx. 0.5kg*Prices are for a set of two (for positive and negative poles). (DC150-4P3M-M12M12 is a set of 4 (2 fo...

Load cable (with voltage current, and temperatur sensing cable.) Rating: 50 A Length: Approx. 5 m Thermistor installed Maximum operating temperature: 105 °C

Cable length: 1.5m Test lead (accessory) Compatible model: TOS7210S

Load cable (7m)For PFX2021kit

Output cable for PFX242110Vdc/80A AWG4 Length approx. 5m

Load cable (7m)For PFX2021Pre-assembled product

Load cable (7m)For PFX2011Pre-assembled product

Output cable for PFX243110Vdc/80A AWG4 Length approx. 5m

Load cable (7m)For PFX2011kit

Impedance measurement cablesCable length: 1m

Impedance measurement cablesCable length: 3m

Impedance measurement cablesCable length: 5m

For PLZ-5W series connection

For connecting PWR-01 series

Cables for Parallel operation and tracking operation for AC electronic loads (for control signals) Cable length: approx. 30 cm

200A 3m (between PFX2532 and battery) Cable set for connection of 60cm between each device (with sensing cable) Rated current: 200 A Sample cable total length 3m Total length of cable between devices: 60 cm Voltage sensing cable with thermistor Maximum operating temperature 75°C (sample cable)

Low inductance cable 100A Cable length: 2m Terminal: M8*When used with PBZ20V BP, two TL02-PLZ and TL03-PLZ cables should be used in parallel. Cannot be used when ungrounded. (In case of SR)

Parallel cable (for between main unit and booster, approx. 55 cm)

Cable length: 50 cm

Low inductance cable 100A Cable length: 1m Terminal: M8*When used with PBZ20V BP, two TL02-PLZ and TL03-PLZ cables should be used in parallel. Cannot be used when ungrounded. (In case of SR)

Required for parallel operation of PLZ-5W/5WH2 series depending on the number of units connected.Cable length: approx. 30 cm *1 cable is included with PLZ2405WB (booster)

Required for parallel operation of the PLZ-5WH2 series, depending on the number of units connected.Cable length: approx. 1 m * Included in PLZ12005WH2 and PLZ20005WH2.

For OP01-PIA and PMC-A (14-pin connector)Approx. 1.0m*Discontinued and only available while supplies last

Parallel cable (between main unit and booster, approx. 30 cm)
